基于PF_RING的多核视频流高性能传输模型

李欣; 樊志杰; 曹志威; 胡正梁; 陈国梁

doi:10.13700/j.bh.1001-5965.2020.0076

基于PF_RING的多核视频流高性能传输模型

doi: 10.13700/j.bh.1001-5965.2020.0076

李欣^{1, 2},
樊志杰^{2, 3, 4, ,},
曹志威^{3, 4},
胡正梁^{3, 4},
陈国梁^{3, 4}

1.
中国人民公安大学信息技术与网络安全学院, 北京 100038
2.
安全防范技术与风险评估公安部重点实验室, 北京 100038
3.
公安部第三研究所信息安全技术部, 上海 200031
4.
上海辰锐信息科技公司, 上海 200031

基金项目:

国家重点研发计划 2018YFC0807105

详细信息

作者简介:
李欣男，博士，副教授。主要研究方向：网络安全、智能视频处理等

樊志杰男，博士，助理研究员。主要研究方向：网络安全、大数据安全、物联网安全、视频安全等

通讯作者:
樊志杰.E-mail:aaronzfan@126.com

中图分类号: TP399
计量
- 文章访问数: 1023
- HTML全文浏览量: 438
- PDF下载量: 164
- 被引次数: 0
出版历程
- 收稿日期: 2020-03-03
- 录用日期: 2020-04-24
- 网络出版日期: 2020-09-20

High-performance multi-core video stream transmission model based on PF_RING

LI Xin^{1, 2},
FAN Zhijie^{2, 3, 4
, ,},
CAO Zhiwei^{3, 4},
HU Zhengliang^{3, 4},
CHEN Guoliang^{3, 4}

1.
College of Information Technology and Network Security, People's Public Security University of China, Beijing 100038, China
2.
Key Laboratory of Security Prevention Technology and Risk Assessment of the Ministry of Public Security, Beijing 100038, China
3.
Department of Information Security Technology, The Third Research Institute of Ministry of Public Security, Shanghai 200031, China
4.
Shanghai Chenrui Information Technology Company, Shanghai 200031, China

Funds:

National Key R & D Program of China 2018YFC0807105

More Information

Corresponding author: FAN Zhijie.E-mail:aaronzfan@126.com

摘要

摘要:
在视频流高性能传输任务中，视频流量的传输问题已成为一个研究的热点。为此，提出了一种基于PF_RING技术的模型。通过使用PF_RING+TNAPI技术，并结合内存路由表、多核、多队列多线程等相关技术确保视频流的高性能传输。同时为了保证不同网域间共享视频数据的安全传输，提出了一种面向视频控制信令双向物理通道、视频流单向物理通道的视频传输模型。实验结果表明：所提方法在有效吞吐量、CPU使用率和平均误码率方面均取得了10%以上的提升。因此，所提方法通过采用PF_RING+TNAPI技术，同时结合视频传输模型，确保了共享视频数据传输的安全性和高效性。
- PF_RING+TNAPI /
- 内存路由表 /
- 视频控制信令 /
- 视频传输模型 /
- 多核多通道
Abstract:
The problem of video traffic transmission has become a research focus in the task of high-performance video stream transmission. In this paper, a model based on PF_RING is proposed to solve this problem. In this model, PF_RING+TNAPI technology, memory routing table, multi-core, multi-queue multi-threading and other related technologies are used to ensure the high-performance transmission of video stream. At the same time, in order to ensure the safe transmission of shared video data among different network domains, a video transmission model for video control signaling dual channel and video data single channel is proposed. The experimental results show that the performance of the proposed method has been increased by at least 10% in effective throughput, CPU utilization, and average bit error rate. Therefore, by fusing PF_RING+TNAPI technology and video transmission system model, the proposed method ensures the security and efficiency of shared video data transmission.
- PF_RING+TNAPI /
- memory routing table /
- video control signaling /
- video transmission model /
- multi-core and multi-channel

HTML全文

图 1 视频传输系统部署架构

Figure 1. Deployment framework of video transmission system

下载: 全尺寸图片幻灯片

图 2 传统协议栈与PF_RING工作机制的比较

Figure 2. Comparison of working mechanism between traditional protocol stack and PF_RING

下载: 全尺寸图片幻灯片

图 3 PF_RING+TNAPI的实现机制

Figure 3. Implementation mechanism of PF_RING+TNAPI

下载: 全尺寸图片幻灯片

图 4 PF_RING零拷贝的实现机制

Figure 4. Implementation mechanism of PF_RING zero-copy

下载: 全尺寸图片幻灯片

图 5 视频传输系统的视频流传输

Figure 5. Video stream transmission of video transmission system

下载: 全尺寸图片幻灯片

图 6 SnifferThread服务框架

Figure 6. Service framework of SnifferThread

下载: 全尺寸图片幻灯片

图 7 测试环境拓扑

Figure 7. Topology of test environment

下载: 全尺寸图片幻灯片

图 8 有效吞吐量对比

Figure 8. Comparision of effective throughput

下载: 全尺寸图片幻灯片

图 9 CPU使用率对比

Figure 9. Comparision of CPU utilization

下载: 全尺寸图片幻灯片

图 10 平均误码率对比

Figure 10. Comparision of average bit error rate

下载: 全尺寸图片幻灯片

表 1 DataNetPortVsas的数据结构

Table 1. Data structure of DataNetPortVsas

属性名	数据类型	属性描述
timelast	time_t	数据报文时间戳
proxyType	IPProxyType	应用层协议类型
netSrcIPPort	NetIPPort	码流的视频源IP地址和端口
setNetDstIPPort	std::set〈NetIPPort〉	码流的视频目标IP地址和端口集合

下载: 导出CSV
