基于跨尺度特征聚合网络的多尺度行人检测

曹帅; 张晓伟; 马健伟

doi:10.13700/j.bh.1001-5965.2020.0069

基于跨尺度特征聚合网络的多尺度行人检测

doi: 10.13700/j.bh.1001-5965.2020.0069

青岛大学计算机科学技术学院, 青岛 266071

基金项目:

国家自然科学基金 61902204

山东省自然科学基金 ZR2019BF028

详细信息

作者简介:
曹帅男, 硕士研究生。主要研究方向:行人检测和计算机视觉

张晓伟男, 博士, 讲师。主要研究方向:图像/视频分析和理解、计算机视觉和机器学习

通讯作者:
张晓伟, E-mail:xiaowei19870119@sina.com

中图分类号: V221⁺.3;TB553
计量
- 文章访问数: 1094
- HTML全文浏览量: 342
- PDF下载量: 200
- 被引次数: 0
出版历程
- 收稿日期: 2020-03-02
- 录用日期: 2020-04-09
- 网络出版日期: 2020-09-20

Trans-scale feature aggregation network for multiscale pedestrian detection

College of Computer Science and Technology, Qingdao University, Qingdao 266071, China

Funds:

National Natural Science Foundation of China 61902204

Natural Science Foundation of Shandong Province of China ZR2019BF028

More Information

Corresponding author: ZHANG Xiaowei, E-mail:xiaowei19870119@sina.com

摘要

摘要:
行人的空间尺度差异是影响行人检测性能的主要瓶颈之一。针对这一问题，提出了跨尺度特征聚合网络（TS-FAN）有效检测多尺度行人。首先，鉴于不同尺度空间呈现出的特征差异性，引入一种基于多路径区域建议网络（RPN）的尺度补偿策略，其在多尺度卷积特征层上自适应地生成一系列与其感受野大小相对应的候选目标尺度集。其次，考虑到不同层次卷积特征在视觉语义上的互补性，提出了跨尺度特征聚合网络模块，其通过横向连接、自上而下路径和由底向上路径，有效地聚合具有语义鲁棒性的高层特征和具有精确定位信息的低层特征，实现对卷积层特征的增强表示。最后，联合多路径RPN尺度补偿策略和跨尺度特征聚合网络模块，构建了一种尺度自适应感知的多尺度行人检测网络。实验结果表明，所提方法与当前一流的行人检测方法TLL-TFA相比，在整个Caltech公开测试数据集上（All：行人高度大于20像素）的行人漏检率降低到26.21%（提高了11.94%），尤其对于Caltech小尺寸行人子数据集上（Far：行人高度在20~30像素之间）的行人漏检率降低到47.30%（提高了12.79%），同时在尺度变化剧烈的ETH数据集上的效果也取得显著提升。
- 行人检测 /
- 尺度感知 /
- 特征金字塔 /
- 特征聚合 /
- 非极大值抑制
Abstract:
Space scale variation of pedestrian instance is one of the main bottlenecks affecting pedestrian detection performance. For this issue, a Trans-Scale Feature Aggregation Network (TS-FAN) is proposed to effectively deal with multi-scale pedestrian detection. First, in view of the feature differences among different scale spaces, we introduce a scale compensation strategy based on multi-path Region Proposal Network (RPN). According to the effectiveness of the convolutional feature layers of different scales, a series of candidate regional scale sets are generated adaptively from the feature maps corresponding to the size of the receptive field. Second, considering the semantic complementarity of convolutional features at different levels, a trans-scale feature aggregation module is proposed to effectively aggregate with semantic robustness highllevel features and with accurate location information of low-level features and achieve enhanced representation ability of convolutional features, by aggregating horizontal connection, top-down path and bottom-up path. Finally, combining the multi-path RPN scale compensation strategy and trans-scale feature aggregation module, we construct a multi-scale pedestrian detection network by adaptive scale perception. The experimental results show that, compared with the state-of-the-art method TLL-TFA, the log-average miss rate of pedestrian detection on widely-used Caltech dataset is reduced to 26.21% (increased by 11.94%) for whole-scale pedestrians (above 20 pixel in height), and 47.30% (increased by 12.79%) for small-scale pedestrian (between 20-30 pixels in height). And the similar improvement is also achieved on ETH dataset with drastic scale variation.
- pedestrian detection /
- scale perception /
- feature pyramid /
- feature aggregation /
- non-maximum suppression

HTML全文

图 1 TS-FAN总体网络架构

Figure 1. TS-FAN overall network architecture

下载: 全尺寸图片幻灯片

图 2 多路径RPN

Figure 2. Multipath region proposal network

下载: 全尺寸图片幻灯片

图 3 多种特征金字塔模型示意图

Figure 3. Schematic diagram of multiple feature pyramid models

下载: 全尺寸图片幻灯片

图 4 特征聚合模块

Figure 4. Feature aggregation module

下载: 全尺寸图片幻灯片

图 5 在Caltech数据集上，本文方法与目前一流方法的对比

Figure 5. Comparison of proposed method with some state-of-the-art methods on Caltech dataset

下载: 全尺寸图片幻灯片

图 6 在ETH数据集上，本文方法与目前一流方法的对比

Figure 6. Comparison of proposed method with some state-of-the-art methods on ETH dataset

下载: 全尺寸图片幻灯片

图 7 在Caltech数据集上，本文方法与目前一流方法可视化效果对比

Figure 7. Comparison of visualized effects of proposed method with some state-of-the-art methods on Caltech dataset

下载: 全尺寸图片幻灯片

图 8 在ETH数据集上，本文方法与目前一流方法可视化效果对比

Figure 8. Comparison of visualized effects of proposed method with some state-of-the-art methods on ETH dataset

下载: 全尺寸图片幻灯片

表 1 在Caltech数据集上对于RPN的消融实验

Table 1. Ablation experiment of RPN on Caltech dataset

特征层	R³⁰⁰/%
特征层	All子集	Far子集	Medium子集	Near子集
C₃	87.7	71.5	90.6	91.9
C₄	92.8	75.2	95.9	97.7
C₅	82.4	59.7	85.4	95.2
P₃₄	95.5	89.1	96.8	97.3
C₃₄	95.3	93.7	95.7	97.9
P₄₅	92.9	76.2	96.3	97.3
C₄₅	93.3	77.3	97.7	97.9
P₃₄₅	93.7	91.1	94.5	93.4
C₃₄₅	97.2	93.7	97.7	97.9

下载: 导出CSV

表 2 Caltech数据集上验证跨尺度聚合特征的有效性

Table 2. Verification of validity of trans-scale aggregation features on Caltech dataset

方法	Proposal	MR^-2/%
方法	Proposal	Reasonable子集	Near子集	Medium子集	Far子集
FPN-P3	C₃	31.29	43.31	31.75	54.06
TS-FAN-H3	C₃	13.84	15.31	20.50	52.80
FPN-P4	C₄	5.33	0.72	24.65	75.41
TS-FAN-H4	C₄	5.12	0.47	20.08	65.50
FPN-P5	C₅	28.45	2.05	75.82	100.00
TS-FAN-H5	C₅	37.96	1.97	82.73	100.00
TS-FAN-H3H4H5	C₄	6.16	1.57	17.24	50.38
TS-FAN-H3H4H5	C₃₄₅	5.53	0.47	13.76	47.30

下载: 导出CSV

表 3 在Caltech数据集不同重叠评估设置上，本文方法与目前一流方法的比较

Table 3. Comparison of proposed method with some state-of-the-art methods on the Caltech dataset under different overlapping evaluation protocols

方法	MR^-2/%
方法	Reasonable子集	All子集	Near子集	Medium子集	Far子集	Partial子集	Heavy子集
FasterRCNN+ATT^[28]	10.33	54.51	1.43	40.75	90.94	22.29	45.18
RPN+BF^[29]	9.58	64.66	2.26	53.93	100	24.23	74.36
AR-Ped^[35]	6.45	58.83	1.37	49.31	100	11.93	48.80
TLL-TFA^[21]	7.40	38.15	0.72	22.92	60.09	18.49	28.66
TS-FAN(本文)	5.53	26.21	0.47	13.76	47.30	10.68	17.82

下载: 导出CSV
