摘要:
将辐射源威胁评估作为多属性决策问题进行处理时，侦察方无法获取敌方辐射源的所有信息，而逼近理想解排序（TOPSIS）法在处理“贫信息”问题时很难得到完美结果，而且其仅仅考虑指标之间的欧氏距离，无法反映各指标间的关联性。针对TOPSIS法存在的问题，将灰色关联分析（GRA）和TOPSIS法结合，提出一种基于博弈论的GRA-TOPSIS辐射源威胁评估模型。在构建辐射源目标综合评价指标体系的基础上，运用博弈论（GT）思想将区间层次分析法（IAHP）所得主观权重和信息熵所得客观权重进行组合得到综合权重，能够较大程度减少单独赋权带来的信息损失。在基于GRA-TOPSIS辐射源威胁评估模型下，构建了关于战场态势的决策信息系统，通过与传统TOPSIS法进行对比仿真，验证了所提方法的有效性，有助于对辐射源进行更精细准确地排序。
-
关键词:
- 逼近理想解排序(TOPSIS) /
- 灰色关联分析(GRA) /
- 博弈论(GT) /
- 辐射源威胁评估 /
- 区间层次分析法(IAHP) /
- 信息熵 /
- 综合权重
Abstract:When the radiation source threat assessment is handled as a multi-attribute decision problem, the scouting party cannot obtain all the information of the enemy radiation source, the method of Technique for Order Preference by Similarity to an Ideal Solution (TOPSIS) is hard to get perfect results in dealing with "poor information", and it only considers the Euclidean distance between the indicators and cannot reflect the correlation between different indicators. Aimed at the problems of TOPSIS method, a radiation source threat assessment model based on game theory is proposed by combining Grey Relational Analysis (GRA) and TOPSIS method. On the basis of constructing the comprehensive evaluation index system of radiation source targets, Game Theory (GT) idea is used to combine the subjective weights of Interval Analytic Hierarchy Process (IAHP) and the objective weights obtained by information entropy to obtain comprehensive weights, which can greatly reduce the information loss caused by the weight alone. Based on the GRA-TOPSIS radiation source threat assessment model, a decision information system for battlefield situation is constructed. By comparing with the traditional TOPSIS method, the effectiveness of the proposed method is verified, which is helpful for sorting radiation sources more precisely and accurately.
-
表 1 脉冲样本图参数
Table 1. Parameters of pulse sequence pattern
目标 RF/MHz PRI/μs PW/μs AOA/(°) PA/dB Ts/μs Te/μs N X1 9 500 3 1.2 11 10 1.00 3 072.00 1 024 X2 9 800 11.4 0.29 2 12 1 340.20 2 799.40 128 X3 9 000 3.1 1.1 30 6 4 510.00 6 097.20 512 X4 1 500 100 1.1 15 11 4 670.00 11 070.00 64 X5 10 000 3 0.5 45 5 7 910.00 9 446.00 512
下载: 导出CSV
表 2 辐射源特征参数
Table 2. Character parameters of emitter
目标 Pt/kW
Fn/dB L/dB (S/N)min/dB tfa/s X1 12 40 4 6 [12, 20] [60, 90] X2 12 40 4 6 [12, 20] [60, 90] X3 13.5 45 3 4 [10, 20] [60, 90] X4 50 48 2 7 [8, 16] [90, 120] X5 15 50 3 6 [10, 18] [50, 80]
下载: 导出CSV
表 3 目标平台态势参数
Table 3. Situation parameters of target platform
目标 A1(l) A2 A3(k) R/km v/(m·s-1) h/m X1 3 80 285 6 000 5 X2 3 50 290 5 500 5 X3 4 120 250 7 000 5 X4 2 400 0 0 2 X5 6 150 0 0 8
下载: 导出CSV
表 4 规范化决策矩阵
Table 4. Normalization decision matrix
目标 R Rr RS, N Pd Pfa/10-9 ΔR Rmax Δv vmax C X1 0.303 6 0.030 5 0.278 5 0.377 7 0.668 3 0.596 5 0.006 9 0.215 7 0.569 0 0.495 1 X2 0.871 2 0.102 6 0.682 3 0.481 1 0.334 2 0.248 5 0.006 9 0.410 3 0.540 5 0.383 6 X3 0.223 6 0.060 8 0.352 3 0.480 6 0.611 5 0.530 2 0.007 0 0.441 4 0.581 2 0.514 1 X4 0.276 0 0.992 0 0.483 7 0.407 1 0.204 2 0.532 0 0.228 5 0.656 6 0.108 1 0.318 8 X5 0.145 2 0.029 6 0.314 3 0.478 7 0.161 4 0.142 5 0.973 5 0.398 9 0.185 9 0.491 6
下载: 导出CSV
表 5 博弈论所赋各指标集化权重
Table 5. Combinational index weights obtained by using game theory
指标层 区间AHP法权重 熵权法权重 GT权重 C1 0.071 3 0.080 9 0.074 8 C2 0.071 3 0.336 2 0.168 5 C3 0.082 9 0.021 2 0.060 3 C4 0.117 9 0.001 9 0.075 4 C5 0.117 9 0.051 3 0.093 5 C6 0.086 2 0.040 7 0.069 5 C7 0.086 2 0.382 6 0.194 9 C8 0.132 8 0.020 8 0.091 7 C9 0.132 8 0.058 5 0.105 5 C10 0.100 8 0.005 8 0.066 0
下载: 导出CSV
表 6 加权规范化决策矩阵
Table 6. Weighted normalization decision matrix
目标 R Rr RS, N Pd Pfa/10-9 ΔR Rmax Δv vmax C X1 0.022 9 0.005 1 0.016 8 0.028 5 0.062 5 0.041 5 0.001 3 0.019 8 0.060 0 0.032 7 X2 0.065 3 0.017 3 0.041 1 0.036 3 0.031 2 0.017 3 0.001 3 0.037 6 0.057 0 0.025 3 X3 0.016 7 0.010 2 0.021 2 0.036 2 0.057 2 0.036 8 0.001 4 0.040 5 0.061 3 0.033 9 X4 0.020 6 0.167 2 0.029 2 0.030 7 0.019 1 0.037 0 0.044 5 0.060 2 0.011 4 0.021 0 X5 0.010 9 0.005 0 0.019 0 0.036 1 0.015 1 0.009 9 0.189 7 0.036 6 0.019 6 0.032 4
下载: 导出CSV
表 7 灰色关联系数矩阵
Table 7. Grey relational coefficient matrix
目标 R Rr RS, N Pd Pfa/10-9 ΔR Rmax Δv vmax C X1 0.571 9 0.998 2 0.699 3 0.979 2 1 0.641 4 1 1 0.537 7 0.979 2 X2 0.996 4 0.821 2 1 0.877 3 0.630 6 0.884 2 1 0.760 4 0.553 4 0.867 9 X3 0.529 1 0.915 7 0.739 5 0.882 8 0.915 7 0.677 5 0.998 2 0.731 9 0.531 1 1 X4 0.558 9 0.258 5 0.826 1 0.929 2 0.579 5 0.675 9 0.566 7 0.583 1 1 0.814 1 X5 0.509 6 1 0.718 9 0.892 6 0.543 8 1 0.230 7 0.770 8 0.873 3 0.974 1
下载: 导出CSV
表 8 不同赋权方法的威胁评估结果
Table 8. Threat assessment results of different weighting methods
目标 主观赋权法 客观赋权法 组合赋权法 相对贴近度 排序结果 相对贴近度 排序结果 相对贴近度 排序结果 X1 0.353 2 3 0.365 2 2 0.614 8 2 X2 0.681 4 1 0.930 5 1 0.628 7 1 X3 0.331 5 4 0.304 0 3 0.568 0 3 X4 0.317 5 5 0.133 5 5 0.331 3 5 X5 0.365 4 2 0.267 7 4 0.458 8 4
下载: 导出CSV
-
[1] 范翔宇, 王红卫, 索中英, 等.基于粗糙集-信息熵的辐射源威胁评估方法[J].北京亚洲成人在线一二三四五六区学报, 2016, 42(8):1755-1761. doi: 10.13700/j.bh.1001-5965.2015.0663FAN X Y, WANG H W, SUO Z Y, et al.Radiator threat evaluation method based on rough set and information entropy[J].Journal of Beijing University of Aeronautics and Astronautics, 2016, 42(8):1755-1761(in Chinese). doi: 10.13700/j.bh.1001-5965.2015.0663 [2] 杨远志, 王红卫, 索中英, 等.基于粗糙集-逼近理想解排序的辐射源威胁排序方法[J].兵工学报, 2016, 37(5):945-952.YANG Y Z, WANG H W, SUO Z Y, et al.An emitter threat evaluation method based on rough set and TOPSIS[J].Acta Armamentarii, 2016, 37(5):945-952(in Chinese). [3] MA S D, ZHANG H Z, YANG G Q.Target threat level assessment based on cloud model under fuzzy and uncertain conditions in air combat simulation[J].Aerospace Science and Technology, 2017, 67:49-53. [4] 韩其松, 余敏建, 高阳阳, 等.云模型和距离熵的TOPSIS法空战多目标威胁评估[J].火力与指挥控制, 2019, 44(4):136-141.HAN Q S, YU M J, GAO Y Y, et al.TOPSIS method based on cloud model and distance entropy in evaluating the air multi-target threat[J].Fire Control & Command Control, 2019, 44(4):136-141(in Chinese). [5] AGARWAL M, BISWAS K K, HANMANDLU M.Generalized ntuitionistic fuzzy soft sets with applications in decision making[J].Applied Soft Computing, 2013, 13(8):3552-3566. [6] ZHANG Q, HU J H, FENG J F, et al.Air multi-target threat assessment method based on improved GGIFSS[J].Journal of Intelligent & Fuzzy Systems, 2019, 36(5):4127-4139. [7] ZHANG K, KONG W R, LIU P P, et al.Assessment and sequencing of target threat based on intuitionistic fuzzy entropy and dynamic VIKOR[J].Journal of Systems Engineering and Electronics, 2018, 29(2):305-310. [8] 陈侠, 刘子龙, 梁红利.基于GA-SLFRWNN的空中目标威胁评估[J].西北工业大学学报, 2019, 37(2):424-432.CHEN X, LIU Z L, LIANG H L.Assessment of aerial target based on genetic algorithm optimizing fuzzy recurrent wavelet neural network[J].Journal of Northwestern Polytechnical University, 2019, 37(2):424-432(in Chinese). [9] 么洪飞, 王宏健, 王莹, 等.基于遗传算法DDBN参数学习的UUV威胁评估[J].哈尔滨工程大学学报, 2018, 39(12):1972-1978.YAO H F, WANG H J, WANG Y, et al.Threat assessment of UUV based on genetic algorithm DDBN parameter learning[J].Journal of Harbin Engineering University, 2018, 39(12):1972-1978(in Chinese). [10] ZENG S Z, XIAO Y.TOPSIS method for intuitionistic fuzzy multiple-criteria decision making and its application to investment selection[J].Kybernetes, 2016, 45(2):282-296. [11] GU T, REN P Y, JIN M Z, et al.Tourism destination competitiveness evaluation in SiChuan province using TOPSIS model based on information entropy weight[J].Discrete and Continuous Dynamical Systems-Series S, 2019, 12(4-5):771-782. doi: 10.3934/dcdss.2019051 [12] CAMBAZOGLU S, YAL G P, EKER A M, et al.Geothermal resource assessment of the Gediz Graben utilizing TOPSIS methodology[J].Geothermics, 2019, 80:92-102. [13] WU J, SUN J S, ZHA Y, et al.Ranking approach of cross-efficiency based on improved TOPSIS technique[J].Journal of Systems Engineering and Electronics, 2011, 22(4):604-609. [14] KHALKHALI A.Best compromising crashworthiness design of automotive S-rail using TOPSIS and modified NSGAⅡ[J].Journal of Central South University, 2015, 22(1):121-133. [15] 杨远志, 于雷, 周中良, 等.基于RS-TOPSIS的空中目标威胁评估[J].北京亚洲成人在线一二三四五六区学报, 2018, 44(5):1001-1007. doi: 10.13700/j.bh.1001-5965.2017.0342YANG Y Z, YU L, ZHOU Z L, et al.Air target threat evaluation based on RS-TOPSIS[J].Journal of Beijing University of Aeronautics and Astronautics, 2018, 44(5):1001-1007(in Chinese). doi: 10.13700/j.bh.1001-5965.2017.0342 [16] 张浩为, 谢军伟, 葛佳昂, 等.改进TOPSIS的多时刻融合直觉模糊威胁评估[J].控制与决策, 2019, 34(4):811-815.ZHANG H W, XIE J W, GE J A, et al.Intuitionistic fuzzy set threat assessment based on improved TOPSIS and multiple times fusion[J].Control and Decision, 2019, 34(4):811-815(in Chinese). [17] DENG J L.Introduction to grey system[J].The Journal of Grey System, 1989, 1(1):1-24. [18] ZHANG M, LI G X.Combining TOPSIS and GRA for supplier selection problem with interval numbers[J].Journal of Central South University, 2018, 25(5):1116-1128. [19] 康长青, 郭立红, 罗艳春, 等.基于模糊贝叶斯网络的态势威胁评估模型[J].光电工程, 2008, 35(5):1-5.KANG C Q, GUO L H, LUO Y C, et al.Model of situation and threat assessment based on fuzzy Bayesian network[J].Opto-Electroic Engineering, 2008, 35(5):1-5(in Chinese). [20] 王睿甲, 王星, 程嗣怡, 等.基于脉冲样本图的机载RWR/ESM辐射源威胁评估[J].电光与控制, 2015, 22(5):19-24. http://www.cnki.com.cn/Article/CJFDTotal-DGKQ201505007.htmWANG R J, WANG X, CHENG S Y, et al.Airborne RWR/ESM threat assessment of radiation source based on pulse sequence pattern[J].Electronics Optics & Control, 2008, 22(5):19-24(in Chinese). http://www.cnki.com.cn/Article/CJFDTotal-DGKQ201505007.htm [21] KAHRAMAN C, ERTAY T.A fuzzy optimization model for QFD planning process using analytic network approach[J].European Journal of Operational Research, 2006, 171(2):390-411. [22] LUO Z, ZHOU J, ZHANG L, et al.A TFN-ANP based approach to evaluate virtual research center comprehensive performance[J].Expert Systems with Applications, 2010, 37(12):8379-8386. [23] 张莹, 王红卫, 陈游.基于ICW-RCM的辐射源组合威胁评估[J].系统工程与电子技术, 2018, 40(3):557-562.ZHANG Y, WANG H W, CHEN Y.Combined emitter threat assessment based on ICW-RCM[J].Systems Engineering and Electronics, 2018, 40(3):557-562(in Chinese). -
