基于响应面方法的印制电路板模型修正

徐飞; 李传日; 姜同敏

doi:10.13700/j.bh.1001-5965.2014.0219

基于响应面方法的印制电路板模型修正

doi: 10.13700/j.bh.1001-5965.2014.0219

北京亚洲成人在线一二三四五六区可靠性与系统工程学院, 北京 100191

详细信息

作者简介:
徐飞(1987—),男,江苏盐城人,博士生,luoyefeihen@163.com

通讯作者:
李传日(1964—),男,福建邵武人,教授,lichuanri@cqjj8.com,主要研究方向为环境试验、振动与冲击试验.

中图分类号: TP391.9
计量
- 文章访问数: 1083
- HTML全文浏览量: 52
- PDF下载量: 624
- 被引次数: 0
出版历程
- 收稿日期: 2014-04-22
- 网络出版日期: 2015-03-20

Printed circuit board model updating based on response surface method

School of Reliability and Systems Engineering, Beijing University of Aeronautics and Astronautics, Beijing 100191, China

摘要

摘要: 近年来,基于响应面的优化分析技术被用于有限元模型修正.给出了基于响应面方法的印制电路板(PCB,Printed Circuit Board)模型修正过程.首先利用ANSYS计算PCB的前6阶模态频率并与模态试验结果进行相关性分析;然后分别利用有限元分析和模态试验的前3阶模态频率构造3个目标函数,再利用前6阶共振频率的残差平方和构造第4个目标函数,每个共振频率的权重相同;最后利用多目标函数遗传算法进行优化分析,使得4个目标函数最小化.给出了一个案例对上述的修正过程进行了阐述.分析结果表明,基于响应面的模型修正技术可用于改善PCB的有限元模型,且可利用已有的商业有限元软件直接进行分析,易于工程应用.
- 响应面 /
- 印制电路板 /
- 有限元分析 /
- 模型修正 /
- 优化分析
Abstract: Optimization analysis based on response surface is used in finite element (FE) model updating in recent years. Printed circuit board (PCB) model updating process based on response surface was presented. First six modal frequencies of PCB were calculated using ANSYS and correlated with modal test results. Three objective functions were formed using the first three orders of FE analytical and measured modal frequencies. The fourth objective function was formed by the square of residuals between first six resonant frequencies. Each resonant frequency was given the same weight. A multi-objective genetic algorithm (MOGA) was used in optimized analysis to minimize the four objective functions. A case was presented to illustrate the proposed updating procedure. The results show that the model updating technique based on response surface can be used to improve the accuracy of PCB FE model, and can be analyzed directly by using commercial FE softwares now available, which is conducive to engineering application.
- response surface /
- printed circuit board /
- finite element analysis /
- model updating /
- optimization analysis

HTML全文

参考文献(24)

[1]	Baruch M. Optimization procedure to correct stiffness and flexibility matrices using vibration tests[J].AIAA Journal,1978,16(11): 1208-1210.
[2]	Baruch M, Bar Itzhack I Y.Optimal weighted orthogonalization of measured modes[J].AIAA Journal,1978,16(4):346-351.
[3]	Baruch M. Methods of reference basis for identification of linear dynamic structures[J].AIAA Journal,1984,22(4):561-564.
[4]	Berman A. Optimal weighted orthogonalization of measured modes-comment[J].AIAA Journal,1979,17(8): 927-928.
[5]	Berman A, Nagy E J.Improvement of a large analytical model using test data[J].AIAA Journal,1983,21(8):1168-1173.
[6]	Fox R, Kapoor M,Rate of change of eigenvalues and eigenvectors[J].AIAA Journal,1968,6(12)2426-2429.
[7]	Mottershead J E, Friswell M I.Model updating in structural dynamics:a survey[J].Journal of Sound and Vibration,1993,167(2) :347-375.
[8]	Friswell M I, Mottershead J E.Finite element model updating in structural dynamics[M].Dordrecht:Kluwer Academic Publishers,1995:158-256.
[9]	Natke H G, Lallement G,Cottin N.Properties of various residuals within updating of mathematical models[J].Inverse Problems in Engineering,1995,1(4)329-348.
[10]	Khodaparast H H, Mottershead J E,Friswell M I.Perturbation methods for the estimation of parameter variability in stochastic model updating[J].Mechanical Systems and Signal Processing,2008,22(8):1751-1773.
[11]	Shahverdi H, Mares C,Wang W,et al.Clustering of parameter sensitivities:examples from a helicopter airframe model updating exercise[J].Shock and Vibration,2009,16(1):75-88.
[12]	Mottershead J E, Link M,Friswell M I.The sensitivity method in finite element model updating:a tutorial[J].Mechanical Systems and Signal Processing,2011,25(7):2275-2296.
[13]	Ren W X, Fang S E,Deng M Y.Response surface-based finite-element-model updating using structural static responses[J].Journal of Engineering Mechanics,2010,137(4):248-257.
[14]	Ren W X, Chen H B.Finite element model updating in structural dynamics by using the response surface method[J].Engineering Structures,2010,32(8):2455-2465.
[15]	Zhou L R, Yan G R,Ou J P.Response surface method based on radial basis functions for modeling large-scale structures in model updating[J].Computer-Aided Civil and Infrastructure Engineering,2013,28(3):210-226.
[16]	Pitarresi, J M.Modeling of printed circuit cards subject to vibration[C]//IEEE Proceedings of the Circuits and Systems Conference.Piscataway,NJ:IEEE,1990,3:2104-2107.
[17]	Pitarresi J M, Celetka D,Coldwel R,et al.The smeared properties approach to FE vibration modeling of printed circuit cards[J].ASME Journal of Electronics Packaging,1991,113(3)250-257.
[18]	Pitarresi J M, Primavera A.Comparison of vibration modeling techniques for printed circuit cards[J].Journal of Electronic Packaging,1992,114(4)378-383.
[19]	Lim G, Ong J,Penny J.Effect of edge and internal point support of a printed circuit board under vibration[J].ASME Journal of Electronic Packaging,1999,121(2)122-126.
[20]	Deiter A, Baker M.Using analysis to design for drop or other shock environment[J].Sound & Vibration,2000,36(10):26-30.
[21]	Li R S. A methodology for fatigue prediction of electronic components under random vibration load[J]Transactions of the ASME,2001,123(4)394-400.
[22]	Amy R A, Aglietti G S,Richardson G.Sensitivity analysis of simplified printed circuit board finite element models[J].Microelectronics reliability,2009,49(7):791-799.
[23]	Amy R A, Aglietti G S,Richardson G.Accuracy of simplified printed circuit board finite element models[J].Microelectronics Reliability,2010,50(1):86-97.
[24]	刘孝保,杜平安, 夏汉良,等.一种面向动态分析的PCB板等效建模方法[J].仪器仪表学报,2011,32(4):863-869. Liu X B,Du P A,Xia H L,et al.Dynamic property analysis-oriented PCB equivalent modeling method[J].Chinese Journal of Scientific Instrument,2011,32(4):863-869(in Chinese).
