| Citation: | LIU J T，GONG X Q，ZHOU N C，et al. Equipment interference and correction method in dynamic pressure field verification of low-speed wind tunnel[J]. Journal of Beijing University of Aeronautics and Astronautics，2025，51（5）：1651-1661 （in Chinese） doi: 10.13700/j.bh.1001-5965.2023.0310
|
As one of the quality indexes of the wind tunnel flow field, the dynamic pressure field of the wind tunnel directly affects the accuracy of experiment results, and the dynamic pressure field needs to be checked regularly. Dynamic pressure field verification equipment includes a five-hole probe, pipe rack, and guide rail (longitudinal beam and cross beam). The influence of verification equipment needs to be deducted when the dynamic pressure field is analyzed. Based on the national general computational fluid dynamics (CFD) software NNW-FlowStar for numerical wind tunnel engineering, a class of low-speed pressure outlet boundary conditions for simulating boundary layer flow was established. The residual convergence and calculation accuracy of the boundary conditions were verified by the low-speed flat plate turbulent boundary layer. Based on unstructured hybrid mesh and FlowStar, the numerical simulation of the FL-12 low-speed wind tunnel test section without any equipment, the test section only with the guide rail of the pipe rack, and the test section with both the pipe rack and the guide rail was carried out. The degree of influence and affected areas of the equipment were qualitatively displayed through a spatial dynamic pressure cloud diagram. The degree of influence of the verification equipment on the dynamic pressure of the test sections was given quantitatively through the spatial dynamic pressure distribution curve. In addition, the state with and without the guide rail of the pipe rack at the top of the test sections was numerically simulated, and the degree of influence of the guide rail of the pipe rack on the dynamic pressure of the test sections was obtained. The guide rail of the pipe rack had a great influence on the adjacent four probes. By decomposing the degree of influence of the verification equipment on the dynamic pressure and comparing the dynamic pressure correction curves of numerical and experimental results, the results show that the degree of influence of the guide rail of the pipe rack on the dynamic pressure of the central probe is six times that of the pipe rack. This verifies the rationality of the experimental dynamic pressure correction scheme ignoring the degree of influence of the pipe rack, and optimization suggestions to improve the accuracy of dynamic pressure verification are proposed.
